Description

  • Application
    The ships constructed on or after 1 January 2016 designed to carry containers on or above the weather deck shall carry at least one water mist lance.
  • Structure and Material
    Water mist lance : SS316
    Hammer: 45# steel ( nickel plated )
  • Standard:conform to MSC.365(93) as amendment

Norminal Pressure and flow : 50L/min @0.6Mpa
Maximum Working Pressure : 1 Mpa
Jetting Range : 6m @0.6 Mpa
Inlet Dimension : DN25

Material of Impact hammer : 45# ( plating nickel on surface )
Drill size :∅19mm,77mm in depth
Length of Impact Hammer : 478mm

Material of Spary lance : SS316
Switch : DN25 Ball valve made of copper alloy
Mist Nozzle : 16x∅ 2mm holes around lance chip
Length of Spray lance : 520mm
Inlet Coupling : STORZ 25A
